SenS 1280

HIGH DEFINITION, HIGH SENSITIVITY SWIR

The SenS 1280 is an industry-leading SXVGA resolution short-wave infrared camera core that delivers high sensitivity and low noise imaging for various specialty applications.

Technical Stats

Detector Type	SWIR InGaAs
Array Format	1280 x 1024
Pixel Pitch	10 micron
Spectral Response	SWIR (0.9 to 1.7 micron)
Frame Rate	60Hz full frame

Digital Video Output	USB3.0, CameraLink
Dual Response	Linear (CTIA) Low & High Gain

Size (L x W x H)	58 x 58 x 70 mm
Weight	<400g
Operating Temperature	-40°C to +71°C
Lens Mounting	C-Mount native

SenS 1280 Signature Features

Short-Wave
Infrared

Developed by short-wave infrared specialists, New Imaging Technologies, the SenS 1280 is a versatile VGA resolution InGaAs short-wave infrared (SWIR) camera core with powerful capabilities for a wide variety of applications. Linear (LIN) response mode allows users to have maximum sensitivity in low light situations.

The camera also features powerful gated imaging functionality for niche applications in security, surveillance, counter UAS, 3D mapping and more.

As an authorized reseller of the SenS 1280, Sierra-Olympia Technologies offers superior service and integration support on these highly capable InGaAs specialty cameras across QVGA, VGA, and HD resolutions.

Bad pixels replacement and smart non-uniformity correction
USB 3.0, CameraLink interfaces
Linear response mode delivers high sensitivity

1 SenS 1280 Videos

Technical Video: SenS 1280 short-wave infrared camera core by NIT

Exceptional Guidance From Sales Through Support

Work with our amazing sales team to making sure you have the correct specifications and are purchasing the right camera for the job. After you’ve purchased the camera our world class support team can help troubleshoot any issues that may come up.
